Colour binding Roll-Up 3
Roll-Up 3
With Roll-Up 3 the sender becomes part of the message. The functional insert on the premium frontal cassette casing is ideal, for example to position the respective brand logo where it is clearly visible and perceptible. A powerful appearance – and secure too, since the system's discreet rear leg provides added stability.Details
✓ Design that makes the difference – thanks to straightforward customisation.
✓ Meaningful function as an element of good form: the system's fold-out leg.
✓ Fast exchange of graphics also with the housing cover.
✓ The housing and cassette complement each other, creating a versatile unit.
✓ Compact package: CHANGE UP THREE comes in a sturdy and functional tote bag.
✓ Meaningful function as an element of good form: the system's fold-out leg.
✓ Fast exchange of graphics also with the housing cover.
✓ The housing and cassette complement each other, creating a versatile unit.
✓ Compact package: CHANGE UP THREE comes in a sturdy and functional tote bag.
FORMATS
850/1000 x 1800 - 2400 mm
Small print at foot: 850/1000 x 90 mm
Our Roll-Ups are printed in proof quality with EPSON Ultrachrome HDX inks on the printing system with the most accurate color reproduction of the entire print market. In addition to cyan, magenta, yellow and black, the printing system is equipped with orange, green and violet as additional colors, giving it an enormous color range. Most Pantone or HKS colors can therefore be reproduced accurately on the Roll-Up. Your print data is processed on the most modern Fiery XF RIP systems and processed including spot colors, overprinting, trapping etc. Our color management system processes CMYK, RGB, grayscales and LAB color spaces exactly as for a contract proof and passes on the data in the highest print quality. The color representation on the roll-up corresponds exactly to your ordered color space. You can place our roll-up in ISOCoatedV2 with two PANTONE spot colors right next to your 6-color printed image brochure and will have a precise color match. Thus our roll-ups are perfect for demanding motifs and photographs or for the representation of spot colors.
Our Roll-Up print is about 30 centimeters longer than the pure Roll-Up motif. Below the motif is a 10 cm high white area, below which you will find, usually invisible rolled in the cassette, the job ticket with important information about printing and print data, RIP, printer, rendering intent and the printing profiles used. In addition, the UGRA-Fogra media wedge CMYK 3.0 is printed. After printing, the media wedge is measured and a test certificate is printed to confirm the quality of the Roll-Up Print under the job ticket.
You can only see this additional information if you remove the Roll-Up from the cassette slightly further than necessary. If you set up the Roll-Up normally, this information is not visible.
Our Roll-Up printing is optimally designed for indoor use, moisture and a few water drops can not harm it, since the pigment inks can also be used in short-term outdoor use. The print is not laminated however, and our Roll-Up hareware is also not suitable for outdoor use in wind and weather.
Our Roll-Ups are printed in proof quality with EPSON Ultrachrome HDX inks on the printing system with the most accurate color reproduction of the entire print market. In addition to cyan, magenta, yellow and black, the printing system is equipped with orange, green and violet as additional colors, giving it an enormous color range. Most Pantone or HKS colors can therefore be reproduced accurately on the Roll-Up.
Your print data is processed on the most modern Fiery XF RIP systems and processed including spot colors, overprinting, trapping etc. Our color management system processes CMYK, RGB, grayscales and LAB color spaces exactly as for a contract proof and passes on the data in the highest print quality. The color representation on the roll-up corresponds exactly to your ordered color space. You can place our roll-up in ISOCoatedV2 with two PANTONE spot colors right next to your 6-color printed image brochure and will have a precise color match. Thus our roll-ups are perfect for demanding motifs and photographs or for the representation of spot colors.
Our roll-up print is about 30 centimeters longer than the pure roll-up motif. Below the motif is a 10 cm high white area, below which you will find, usually invisible rolled in the cassette, the job ticket with important information about printing and print data, RIP, printer, rendering intent and the printing profiles used. In addition, the UGRA-Fogra media wedge CMYK 3.0 is printed. After printing, the media wedge is measured and a test certificate is printed to confirm the quality of the Roll-Up Print under the job ticket. You can only see this additional information if you remove the roll-up from the cassette slightly further than necessary. If you set up the roll-up normally, this information is not visible.
We use a satin-white microporous-coated PET paper made of polyester with opaque, gray antistatic backing for the color fidelity Roll-Ups.
The Roll-Up paper is suitable for extremely high-resolution printing images. Due to its good stiffness and strength, the non-sensitive paper offers an excellent plan position under various climatic conditions and is therefore very easy to use. It is dimensionally stable, tear-resistant and opaque.
The satin-white coating provides a very good color presentation and enables previously unknown photographic qualities in combination with our Ultrachrome HDX pigment inks from Epson. The high-quality satin surface minimizes disturbing reflections.
Surface weight: 250 g/m²
Thickness: 190 μm
Color location D50/2° M0: L* 95.0 a* 0.2 b* -5.0
Flexural stiffness along: 300 nN
Gloss 60°: >20
Print Template
PDF Template - Format 850 x 2.000 mm
PDF Template - Format 850 x 2.400 mm
PDF Template - Format 1.000 x 2.000 mm
PDF Template - Format 1.000 x 2.400 mm
Most customers send us PDF data. We accept PDF, EPS, TIF and JPEG files for proofing.
Black-and-white, CMYK or even files with PANTONE and HKS or TOYO spotcolors. PDF files in PDF/X-1a, PDF/X-3 or PDF/X-4 format are ideal for proofing.PDF/X-1a (widely distributed outside of Europe) and PDF/X-3 are traditionally the PDF files optimized for printing. These ISO standards represent e.g. fonts and images are surely embedded. They are recognized and requested as the standard for data exchange of print data at most printers.
PDF/X-4 is the new printing standard for PDF files. Unlike PDF/X-3, PDF/X-4 files can contain transparencies. PDFX-3 was already a medaneutral standard, but 99% of all X-3 files contain only CMYK colors and spot colors. PDF/X-4 is still rare, but more and more requested by printers, as X-4 data can be separated as late as possible into the process chain. The standard offers many advantages, but also some risks.
Proof GmbH is the only company in Germany to be certified by PDFX-ready for the proof output of PDF / X-4 data and has been a member of PDFX-ready for several years.
If you want to know exactly the pros and cons of the respective formats, we recommend the pages of the Swiss PDFX-ready Initiative. Here you will find competent information, PDF creation guides and Acrobat Creation and Acrobat test profiles for PDF / X-4 files, although the information given in english is not as comprehensive as the germanspeaking webpages. PDFX-ready offers:
PDFX-ready PDF / X creation guide
PDF preflights for Adobe Acrobat
Creator workflows for sheetfed, web offset and newspaper printing
In all standard layout programs, all three PDF/X standards can be selected and created during output.
You can upload one or more files to each article after the order is completed. Each file can be up to 2 GB in size.
For example, you order 10 in the format A3 and 2 in the format DIN A2. After the order has been completed, you can upload a file with 10 pages in DIN A3 format to DIN A3 format and two files in A2 format with one page each. If we are to make several copies of one proof, please let us know about during the order process in the "commentary" field.
The figure shows how your order of a DIN A4 proof looks before the upload.
You now select and upload your file to be projected.
After the upload, you can check your proof data again, delete files and reupload or upload others.
When finished uploading, complete the order by clicking the button "COMPLETE YOUR ORDER".
Your order will no longer be editable for you. We get the message that we can now start with the data check and the proofing.
You can view your order at any time, but after completion you cannot change it any longer.
If your proofing data shows faults during the data check, we will reopen the order again, so that you can delete the faulty data and upload correct files. Then complete the order again.
Your uploaded files for proofing currently remain on our server for at least 1 year, and can be viewed and downloaded during this time.
Please feel free to contact us if you have any questions to Roll-Ups.
Phone: +49 (0) 7071-7952740
Mon - Fri: 9 am - 6 pm
- Which profile is right for me?
- How do I create the PDF file?
- How fast can you send the ?
- ...?
Outside of our opening times, you can always send us an email with your questions, which we will answer as soon as possible: info@proof.de
We have compiled the most important questions for you here: Frequently asked questions about Proofs
A lot of knowledge about Proof, Digitalproof, Onlineproof and Colorproof can be found here: proofing.de
Matthias Betz and the Proof.de team
Shipping costs and delivery times
Postage and packaging to Germany
| Roll-Up: |
| DHL Paket: € 9,- Next-Day before 12 am: € 19,- Next-Day before 9 am: € 39,- Next-Day with delivery on a Saturday: € 29,- |
| The regular running time of shipments within Germany is 1 to 4 working days, in exceptional cases longer. Express shipments will be the next working day. Please note that the production of the rollups can take up to 3 working days. |
Postage and Packaging to the EU: |
| Roll-Up: |
| DHL / UPS Paket: € 19,- DHL / UPS : € 45,- |
| The regular running time of shipments to the EU is 2 to 5 working days, in exceptional cases longer. Express shipments are usually the next working day. Please note that the production of the rollups can take up to 3 working days. |
Postage and Packing Non EU Europe, Switzerland and North America: |
| Roll-Up: |
| DHL Paket: € 25,- DHL / UPS : € 55,- |
| The regular running time of shipments Switzerland is 2 to 5 working days, non EU Europe in exceptional cases longer. Express shipments are the next working day in Switzerland, non EU Europe may be longer. Please note that the production of the rollups can take up to 3 working days. |
Postage and Packing Rest of the World |
| Roll-Up: |
| DHL Paket: € 45,- DHL / UPS : € 75,- |
| The regular running time of shipments to worldwide countries is up to 15 working days, in exceptional cases longer. Express shipments are usually sent within four business days. Please note that the production of the rollups can take up to 3 working days. |
The shipping zones are regulated differently by Deutsche Post, DHL and partly. To determine your exact price, please log in and add the required to your shopping basket. After entering the delivery address, the shop will display the individual shipping options and calculate the shipping costs correctly. For questions, please call us. * Working day = Monday to Friday No shipping and no delivery on holidays in Germany. |
Country assignment for shipping by post or DHL / UPS standardThe country assignments for shipping are listed here in detail. |
Current proofing systems can reproduce spot colors such as HKS or Pantone very well. With the Fiery XF 7.0.1 proofing software and the Epson SureColor-P9000V Spectro proof printer, we have evaluated the color deviation in Delta-E00 with which the various PANTONE and HKS colors can be printed on our roll-up substrate.
The color deviations were calculated by the proofing software on the basis of the measured color space of the proof.de proofing system. Deviations are therefore possible in practice. However, it turns out that almost all spot colors can be simulated quite well in the large color space of the proofing device.
The smaller the ∆E00 value, the smaller the color distance from the spot color reference to the printed color. Higher ∆E values show which colors can be reproduced more poorly in the proof.
As a rough guide: From ∆E00 > 1 a color difference is visible to the human eye, below it it can only be measured, but not seen.
The color deviations were calculated by the proofing software on the basis of the measured color space of the proof.de proofing system. Deviations are therefore possible in practice. However, it turns out that almost all spot colors can be simulated quite well in the large color space of the proofing device.
The smaller the ∆E00 value, the smaller the color distance from the spot color reference to the printed color. Higher ∆E values show which colors can be reproduced more poorly in the proof.
As a rough guide: From ∆E00 > 1 a color difference is visible to the human eye, below it it can only be measured, but not seen.
| Roll-Up-Foil PET-Foil, 250 g/m², grey antistatic back |
| Pantone Solid Coated |
| Pantone Metallics Coated |
| Pantone Premium Metallics Coated |
| Pantone Goe Guide Coated |
| HKS K |
| HKS K 3000 Plus |
